ICP DAS ICP CON I-7033 3-channel RTD Input Pt100, Pt1000, Ni120 RS-485 Modbus

ICP DAS ICP CON I-7033 3-channel RTD Input Pt100, Pt1000, Ni120, RS-485 Modbus.

• 3-channel RTD Input
• Lead Resistance Elimination for 3/4-wire Connections
• Open Wire Detection
• 4 kV ESD Protection
• 3000 VDC Intra-module Isolation
• Dual Watchdog
• Wide Operating Temperature Range: -25 to +75°C

The I-7033 is a 3-channel RTD Input module that is used for measuring temperatures via an RTD sensor and supports Pt100, Ni120, and Pt1000 type sensors. The module allows 2/3/4-wire RTD connections and features open wire detection. In addition, the I-7033 also includes 3000 VDC intra-module isolation, and supports lead resistance elimination for 3/4-wire connections.

Building Automation, Factory Automation, Machine Automation, Remote Maintenance, Remote Diagnosis, Testing Equipment.

Models I-7033 I-7033D M-7033 M-7033D RTD Input Channels 3 Wiring 2/3/4-wire Sensor Type Pt100, Pt1000, Ni120 Resolution 16-bit Accuracy ±0.1% Sampling Rate 15 Hz Individual Channel Configuration No Overvoltage Protection ±25 VDC Open Wire Detection Yes 3/4-wire RTD Lead
Resistance Elimination Yes Resistance Measurement 3.2 kΩ Max.



Models I-7033 I-7033D M-7033 M-7033D Communication Interface RS-485 RS-485 Bias Resistor No (An RS-485 master is required to provide the bias.) Format (N, 8, 1) (N, 8, 2) (E, 8, 1) (O, 8, 1) Baud Rate 1200 ~ 115200 bps Protocol DCON Modbus RTU, DCON Dual Watchdog Yes, Module (1.6 Seconds), Communication (Programmable) LED Indicator/Display System LED Indicator Yes, 1 as Power/Communication Indicator I/O LED Indicator - 7-Segment LED Display - Yes - Yes Isolation Intra-Module Isolation, Field-to-Logic 3000 VDC EMS Protection ESD (IEC 61000-4-2) ±2 kV Contact for each Terminal EFT (IEC 61000-4-4) ±4 kV to Power Line Surge (IEC 61000-4-5) ±0.5 kV for Power Line Power Reverse Polarity Protection Yes Input Range +10 ~ +30 VDC Consumption 1.0 W 1.6 W 1.0 W 1.6 W Mechanical Dimensions (L x W x H) 123 mm x 72 mm x 35 mm Installation DIN-Rail or Wall Mounting Environment Operating Temperature -25 ~ +75°C Storage Temperature -40 ~ +85°C Humidity 10 ~ 95% RH, Non-condensing

New, in opened package.
