Siemens QBE2002-P16 HVAC Pressure Sensor 0...16bar 0...1.6MPa 0...232.0psi 0…10V

Pressure Sensor Siemens QBE2002-P16 for liquid and gaseous media

New, in factory box.

• Piezo-resistive measuring system
• DC 0 ...10 V output signal
• Measurement unaffected by changes in temperature
• High temperature stability
• No mechanical aging or creepage
• External thread G½"
• Excellent EMC characteristics

The pressure sensors are suitable for the measurement of static and dynamic positive pressure in HVAC plant, particularly in hydraulic and pneumatic systems using liquid or gaseous media (steam applications).

The pressure sensors operate on the piezo-resistive measuring principle. The ceramics diaphragm (thick-film hybrid technology) acquires the pressure through direct contact with the medium. The measurement is converted electronically into a linear output signal of DC 0...10 V.
